Ubiquiti UICARE-UVC-AI-PTZ-W

Beschreibung

Industrial-grade 4K PoE++ PTZ camera with enhanced AI capabilities, 22x optical zoom, and long-range adaptive IR LED night vision.

Technische Daten

Capacity

128/256/512 GB/1 TB

Mounting

Wall, Pole mount, Desk stand (Included)

Connector

(2) Shielding RJ45

Standards

TIA/EIA-568-B.2 ISO/IEC 11801

Zoom Mode

22x Optical

Dimensions

207 x 223.7 x 341.3 mm (8.2 x 8.8 x 13.4")

In the Box

(1) Gate Hub (1) Intercom (1) PoE++ adapter (2) 2-wire PoE extenders

Resolution

4K

Bend Radius

Min. 50.4 mm (1.98'')

Form Factor

microSDXC™

Speed Class

Class 10, UHS-I (U1), V10

Flame Rating

VW-1 (UL1581)

Pack Options

Single Unit

Field of View

Wide: H: 59.8°, V: 44.4° , D: 70° Tele: H: 3°, V: 2.24° , D: 3.76°

UV Resistance

ASTM G 151/154

Conductor Type

Stranded copper

Gate Hub: LEDs

W/B <a href="https://help.ui.com/hc/en-us/articles/25738084762775-UniFi-Access-Understand-Access-Device-LED-Status-Indicators" target="_blank" rel="noopener noreferrer">Learn More</a>

Intercom: LEDs

Amber <a href="https://help.ui.com/hc/en-us/articles/25738084762775-UniFi-Access-Understand-Access-Device-LED-Status-Indicators" target="_blank" rel="noopener noreferrer">Learn More</a>

Intercom: Size

177 mm (7") diagonal

Pan-Tilt Range

Pan: 360° (Endless) Tilt: 120°

Shielding Type

S/FTP

Endurance (TBW)

128 GB: 64 256 GB: 128 512 GB: 500 1 TB: 1,000

IR Night Vision

100 m (328 ft)

Jacket Diameter

6.3 mm (0.25")

Jacket Material

Thermoplastic elastomer (TPE)

Weatherproofing

IP66

Available Colors

White, Black

Gate Hub: Button

(1) Factory reset

Gate Hub: Weight

460 g (1 lb)

Hardware: Button

(1) Factory reset

Hardware: System

R/G/B/W

Hardware: Weight

Without mount: 3.8 kg (8.4 lb) Wall mount (Pedant): 3 kg (6.6 lb) Table stand: 150 g (5.3 oz) Pole mount: 320 g (11.3 oz)

Intercom: Weight

Device: 965 g (2.1 lb) Bracket: 445 g (1 lb)

Available Lengths

1, 2, 3, 5, 8 m (3.3, 6.6, 9.8, 16.4, 26.3 ft)

Grid overview: AI

Enhanced AI

Grid overview: IR

100 m (328 ft)

Hardware: Buttons

(1) Factory reset

Intercom: Buttons

(1) Factory reset

Intercom: Sensors

Proximity sensor ALS sensor

Intercom: Speaker

(1) Yes, 2W

Performance: Lens

F 6.36-138.5 mm; ƒ/1.5-ƒ/3.4

Gate Hub: Mounting

DIN-rail (Included)

Intercom: Mounting

Wall mount, adapter to the gooseneck pedestal (Included) Surface angle, flush mount, sunshield kit (Optional)

Mechanical: Weight

Device: 1.55 kg (3.4 lb) Articulating mount: 1.3 kg (2.9 lb)

Supported PoE Type

Up to PoE+++

Conductor Wire Gage

24 AWG

Grid overview: Zoom

22x Optical Zoom

Hardware: Processor

Quad-core Arm® Cortex®-A53 based chip

Intercom: Luminance

Max. 1000 nits (Typical)

Performance: Sensor

1/1.8" 8MP

Supported Data Rate

GbE

Gate Hub: Dimensions

175 x 126 x 26 mm (6.9 x 5 x 1")

Intercom: Dimensions

324.8 x 113.7 x 28.3 mm (12.8 x 4.5 x 1.1")

Intercom: Resolution

2MP 1200 x 1600 (3:4)

Management Interface

SDA 6.0

PoE++ Adapter: Model

U-PoE++

Operating Environment

Outdoor

PoE++ Adapter: Weight

210 g (7.4 oz)

Gate Hub: Power Method

PoE++ UL 294 Power-limited Class 2 PSU UL 60950-1/62368-1 LPS/PS2 PSU

Gate Hub: UL 294 Level

Destructive attack: Level I Line security: Level I Endurance: Level I Standby power: Level I

Hardware: Power Method

PoE++

Intercom: Connectivity

BLE 4.2 NFC

Intercom: Power Method

PoE UL 294 Power-limited Class 2 PSU UL 60950-1/62368-1 LPS/PS2 PSU

Intercom: UL 294 Level

Destructive attack: Level I Line security: Level I Endurance: Level I Standby power: Level I

Gate Hub: Digital Input

Gate exit request, gate position, side door exit request, side door position, emergency

Gate Hub: PoE Interface

(1) PoE++ input, 50V DC, 1A (4) PoE outputs, 50V DC, 30W per port (Max 55W aggregated)

Intercom: Field of View

H: 79.4°, V: 97.5°, D: 118.2°

Intercom: NFC Frequency

13.56 MHz

Performance: Night Mode

Built-in IR LED illumination and IR cut filter

Performance: Resolution

8MP 3840 x 2160 (16:9)

UniFi Application Suite

Protect

Gate Hub: Certifications

CE, FCC, IC, UL 294, CAN/ULC-60839-11-1

Hardware: Certifications

CE, FCC, IC

Hardware: Expansion Slot

MicroSD card

Hardware: Mount Material

Powder-coated aluminum alloy

Installation Temperature

-20 to 60°C (-4 to 140°F)

Intercom: Certifications

CE, FCC, IC, UL 294, CAN/ULC-60839-11-1

Intercom: Mount Material

Powder-coated stainless steel

Intercom: NFC Read Range

< 30 mm

Intercom: NFC Technology

ISO/IEC 14443A / 14443B / 15693 / 18092 (Ecma 340) MIFARE Classic / MIFARE DESFIRE Sony FeliCa™ (ID only) NFC Forum tags T1T, T2T, T3T, T4T and T5T

Wire PoE Extenders: LEDs

White

Gate Hub: Input Terminals

(1) Gate exit request (1) Gate position (1) Side door exit request (1) Side door position (1) Emergency

Gate Hub: Supported Doors

1 gate, 1 side door

Intercom: Max. Frame Rate

30 FPS

Intercom: Weatherproofing

IP65

PoE++ Adapter: Dimensions

106 x 63 x 34 mm (4.2 x 2.5 x 1.3")

PoE++ Adapter: Efficiency

85+%

Wire PoE Extenders: Model

UACC-Extender-2Wire-PoE-Tx/Rx

Ambient Operating Humidity

5 to 95% noncondensing

Gate Hub: Dry Output Relay

(2) Operator: rated 30V DC, up to 1A (1) Aux: rated 30V DC, up to 1A

Gate Hub: Other locks (1A)

24 AWG length: 9 m (30 ft) 22 AWG length: 15 m (49 ft) 20 AWG length: 24 m (79 ft) 18 UACC-Cable-DoorLockRelay length: 36 m (118 ft)

Gate Hub: UL 294 Statement

Compliance with IEEE 802.3 specifications was not verified as part of UL 294. The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power

Intercom: UL 294 Statement

Compliance with IEEE 802.3 specifications was not verified as part of UL 294. The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power

Wire PoE Extenders: Weight

PoE in: 77 g (2.7 oz) PoE out: 79 g (2.8 oz)

Ambient Storage Temperature

-40 to 80°C (-40 to 176°F)

Grid overview: Weatherproof

Outdoor Exposed

Intercom: Screen Technology

Capacitive multi-touch

Mechanical: Weatherproofing

IP66

Performance: Image Settings

Color, brightness, sharpness, contrast white balance, exposure control 2DNR, 3DNR, NR by motion masking, text overlay

PoE++ Adapter: AC Connector

IEC-320 C6

PoE++ Adapter: Power Method

Universal AC input, 100–240V AC, 50/60 Hz

PoE++ Adapter: Power Supply

AC/DC

Sequential Read Performance

128 GB: 100 MB/s 256 GB: 100 MB/s 512 GB: 160 MB/s 1 TB: 160 MB/s

Gate Hub: Enclosure Material

Polycarbonate

Gate Hub: Maximum User Count

6,000

Hardware: Enclosure Material

Aluminum alloy, polycarbonate

Intercom: Enclosure Material

Aluminum alloy, UV-stabilized polycarbonate, glass

Performance: Max. Frame Rate

30 FPS

PoE++ Adapter: Data In / PoE

RJ45 shielded socket

PoE++ Adapter: Input Current

1.3A @ 120V AC 0.75A @ 230V AC

PoE++ Adapter: Output Ripple

1% max.

PoE++ Adapter: Rated Voltage

100–240V AC at 50/60Hz

PoE++ Adapter: Response Time

<1 ns

Ambient Operating Temperature

-30 to 75°C (-22 to 167°F)

Mechanical: Mounting Material

Stainless steel, aluminum alloy

PoE++ Adapter: Certifications

CE, FCC, IC, UL, UKCA, KC, CCC, KC, RoHS

PoE++ Adapter: Inrush Current

<100A peak @ 120V AC <200A peak @ 230V AC

PoE++ Adapter: Output Voltage

48V DC @ 1.25A

Gate Hub: Networking Interface

(5) 10/100/1000 Base-T

Gate Hub: Powered Output Relay

Side door lock: 12V DC, up to 1A

Gate Hub: Software Information

The software version can be checked at <a href="https://unifi.ui.com/" target="_blank" rel="noopener noreferrer">https://unifi.ui.com</a>

Grid overview: Lens Resolution

4K

Hardware: Networking Interface

(1) 100/10 MbE RJ45 port

Intercom: Networking Interface

(1) GbE RJ45 port

Intercom: Software Information

The software version can be checked at <a href="https://unifi.ui.com/" target="_blank" rel="noopener noreferrer">https://unifi.ui.com</a>

Mechanical: Enclosure Material

UV-stabilized polycarbonate, aluminum alloy

PoE++ Adapter: 4-pair Powering

Pins 1, 2, 4, 5 (+) and 3, 6, 7, 8 (-)

PoE++ Adapter: Line Regulation

≤ 1%

PoE++ Adapter: Load Regulation

≤ 3%

Wire PoE Extenders: Dimensions

40 x 105 x 25 mm (1.6 x 4.1 x 1")

Wire PoE Extenders: Management

(1) 10/100 MbE

Mechanical: Pole Mount Diameter

1—2.5" (25—63.5 mm)

PoE++ Adapter: Surge Protection

Difference and common mode

Gate Hub: Indoor and Outdoor Use

Indoor only: device itself Outdoor: with waterproof junction box

Gate Hub: Management Application

UniFi Access

Gate Hub: Max. Power Consumption

22W (Without PoE output) 60W (With PoE output)

Hardware: Max. Power Consumption

51W

Intercom: Management Application

UniFi Access

Intercom: Max. Power Consumption

13W

PoE++ Adapter: Shunt Capacitance

<5 pF data

Wire PoE Extenders: Power Method

PoE++

Hardware: Supported Voltage Range

42.5–57V DC

Intercom: Supported Voltage Range

48V DC

Performance: Networking Interface

GbE RJ45 port

PoE++ Adapter: Peak Pulse Current

36A (10/1000 μs) data

Wire PoE Extenders: PoE Interface

PoE input: (1) PoE++, 50V DC, Max. 1.2A PoE output: (1) PoE+, 48V DC, 0.72A

Gate Hub: CAN/ULC-60839-11-1 Grade

Grade assignment: I

Gate Hub: PoE Cabling Requirements

Cat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site. The minimal conductor gauge per

Gate Hub: UA-Lock-Electric (400mA)

24 AWG length: 25 m (82 ft) 22 AWG length: 42 m (138 ft) 20 AWG length: 66 m (217 ft) 18 UACC-Cable-DoorLockRelay length: 100 m (328 ft)

Intercom: CAN/ULC-60839-11-1 Grade

Grade assignment: I

Intercom: PoE Cabling Requirements

Cat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site. The minimal conductor gauge per

PoE++ Adapter: Clamping Protection

11V data, 60V power

PoE++ Adapter: Switching Frequency

65 kHz

Wire PoE Extenders: Certifications

CE, FCC, IC

PoE++ Adapter: Max. Surge Discharge

1500A (8/20 μs) power

Gate Hub: Ambient Operating Humidity

5 to 90% noncondensing

Hardware: Ambient Operating Humidity

0 to 90% noncondensing

Intercom: Ambient Operating Humidity

5 to 90% noncondensing

Wire PoE Extenders: Mounting Material

Polycarbonate

PoE++ Adapter: Supported Voltage Range

100–240V AC

Wire PoE Extenders: ESD/EMP Protection

Air: ± 8kV, contact: ± 4kV

Wire PoE Extenders: Enclosure Material

Polycarbonate

Gate Hub: Ambient Operating Temperature

-30 to 60° C (-22 to 140° F)

Hardware: Ambient Operating Temperature

-40 to 50º C (-40 to 122º F)

Intercom: Ambient Operating Temperature

Device: -30 to 60° C (-22 to 140° F) Display: -25 to 60° C (-13 to 140° F)

Gate Hub: UA-Lock-Magnetic-270kg (800mA)

24 AWG length: 12 m (39 ft) 22 AWG length: 20 m (66 ft) 20 AWG length: 30 m (98 ft) 18 UACC-Cable-DoorLockRelay length: 46 m (151 ft)

Gate Hub: UA-Lock-Magnetic-540kg (500mA)

24 AWG length: 20 m (66 ft) 22 AWG length: 32 m (105 ft) 20 AWG length: 51 m (167 ft) 18 UACC-Cable-DoorLockRelay length: 80 m (262 ft)

Wire PoE Extenders: Networking Interface

(1) 10/100 MbE (1) Homeplug AV

PoE++ Adapter: Ambient Operating Humidity

10 to 95% noncondensing

PoE++ Adapter: Ambient Storage Temperature

-30 to 70°C (-22 to 158° F)

Wire PoE Extenders: Max. Power Consumption

3W (Without PoE output)

PoE++ Adapter: Ambient Operating Temperature

0 to 40° C (32 to 104° F)

Wire PoE Extenders: Ambient Operating Humidity

5 to 95% noncondensing

PoE++ Adapter: Max. PoE+ Wattage per Port by PSE

60W

Wire PoE Extenders: Ambient Operating Temperature

-10 to 40° C (14 to 104° F)

Gate Hub: Document number, and issue date and/or revision le

UA-Hub-Gate, V01

Intercom: Document number, and issue date and/or revision le

UA-Intercom, V01
