Ubiquiti SuperLink Glass Break Sensor

Beschreibung

Battery-powered SuperLink sensor featuring advanced glass break detection and motion sensing.

Technische Daten

Mounting

Adhesive and screw mount

Dimensions

Device with wall mount: 134.5 x 22.5 x 24.8 mm (5.3 x 0.9 x 1") Device with corner mount: 134.5 x 22.5 x 27.9 mm (5.3 x 0.9 x 1.1")

Hardware: LEDs

(1) Status: R/B/W (1) Signal: B/R

Performance: EU

865.1–869.5 MHz

Performance: US

915.6–927.6 MHz

Hardware: Weight

With mount and batteries: 70 g (2.5 oz)

Hardware: Buttons

(1) Function button (1) Factory reset (1) Tamper switch

Hardware: Display

1.14" status display

Performance: Thread

2400–2480 MHz

Software: Mobile App

UniFi Protect iOS™ and Android™

Hardware: Battery Life

Up to 3 years

Hardware: Power Method

(2) Lithium battery CR123A

Performance: Bluetooth

2400–2480 MHz

Performance: SuperLink

1 dBi

UniFi Application Suite

Protect

Hardware: Certifications

FCC, IC, CE

Hardware: Mount Material

Polycarbonate

Performance: Connectivity

SuperLink (Proprietary)

Software: Web Application

UniFi Protect

Hardware: Antenna Connector

(1) RP-SMA female

Hardware: Enclosure Material

Polycarbonate

Hardware: Max. Power Consumption

0.2W

Performance: Detected Glass Type

Plate, tempered, obscured, laminated, coated, wired Size: 280 x 356 mm (11 x 14") to 1067 x 1626 mm (42 x 64”) Thickness: 2.4 mm (3/32"), 4.8 mm (3/16"), 3.2 mm (1/8"), 6.4 mm (1/4")

Hardware: Supported Voltage Range

3V

Performance: Networking Interface

(1) 10/100 MbE RJ45 port

Hardware: Ambient Operating Humidity

10 to 90% noncondensing

Hardware: Ambient Operating Temperature

0 to 40° C (32 to 104° F)
