Ubiquiti UAP-AC-M
Ubiquiti · UAP-AC-M · EAN 0810354025792
Lieferzeit auf Anfrage
107,81 €inkl. MwSt., zzgl. Versand
Beschreibung
Compact, indoor/outdoor WiFi 5 AP with 4 spatial streams and optional external antenna support for directional coverage.
Technische Daten
- Höhe
- 35,4 cm
- Tiefe
- 3,4 cm
- Breite
- 4,6 cm
- Uplink
- GbE
- Gewicht
- 0,152 kg
- Mounting
- Wall, Pole (Mounts Included)
- Dimensions
- 353 x 46 x 34.4 mm (13.9 x 1.8 x 1.4")
- Power Method
- PoE
- Coverage Area
- 140 m² (1,500 ft²)
- WiFi Standard
- WiFi 5
- Hardware: 5 GHz
- 15 dBi
- Spatial Streams
- 4
- Weatherproofing
- IPX4
- Hardware: Weight
- 152 g (5.4 oz)
- Hardware: 2.4 GHz
- 10 dBi
- Max. Client Count
- 200+
- Hardware: Max VSWR
- 2:1
- Mechanical: Weight
- 80 g (2.8 oz)
- Performance: 5 GHz
- 2 x 2 (DL MU-MIMO)
- Grid overview: WiFi5
- WiFi 5
- Hardware: Insulation
- Max. Resistance: 1G ohm @ 50V
- Hardware: Management
- Ethernet Bluetooth
- Performance: 2.4 GHz
- 2 x 2 (DL MU-MIMO)
- Performance: 802.11n
- 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
- Grid overview: Uplink
- GbE
- Hardware: Polarization
- Dual-linear
- Mechanical: Dimensions
- 91 x 61 x 32.5 mm (3.6 x 2.4 x 1.3")
- Software: UniFi Network
- Version 6.0.45 and later
- Hardware: Certifications
- CE, FCC, IC, UKCA, Anatel: 01769-18-08356
- Hardware: ESD Protection
- Absorbing transient current with response to surge voltage from 100V/s to 1kV/µs
- Hardware: RF Connections
- (2) RP-SMA
- Performance: Max. BSSIDs
- 8 per Radio
- Hardware: Max. Capacitance
- 1.0 pF @ 1 MHz
- Hardware: Channel Bandwidth
- HT 20/40, VHT 20/40/80 (MHz)
- Hardware: Discharge Current
- 10kA+
- Mechanical: Weatherproofing
- IPX5
- Grid overview: Radio/Antenna
- Omnidirectional
- Hardware: Enclosure Material
- Polycarbonate
- Hardware: Operating Frequency
- US/CA: 2400 - 2472 MHz U-NII-1: 5150 - 5250 MHz U-NII-2A: 5250 - 5350 MHz U-NII-2C: 5470 - 5725 MHz U-NII-3: 5725 - 5850 MHz Worldwide: 2400 - 2483.5 MHz 5150 - 5850 MHz
- Hardware: Pole Mount Diameter
- 1–3" (25–76 mm)
- Hardware: Data Line Protection
- Up to 2.5 Gbps
- Hardware: Networking Interface
- (1) GbE RJ45 port
- Mechanical: Enclosure Material
- Polycarbonate
- Performance: 802.11ac (WiFi 5)
- 6.5 Mbps to 867 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80)
- Hardware: DC Spark-Over Voltage
- 90V @ 100V/s
- Grid overview: Max. Client Count
- 200
- Hardware: Max. Power Consumption
- 8.5W
- Hardware: Supported Voltage Range
- 44–57V DC
- Hardware: Supported Frequency Range
- 2.4–2.5 GHz 5.1–5.9 GHz
- Hardware: Ambient Operating Humidity
- 5 to 95% noncondensing
- Hardware: Ambient Operating Temperature
- -30 to 70° C (-22 to 158° F)
- Hardware: Max. Impulse Spark-Over Voltage
- 700V @ 1kV/µs
- Hardware: Shock and Vibration Certification
- ETSI300-019-1.4 Standard
