Ubiquiti SuperLink Motion Sensor

Beschreibung

SuperLink motion sensor designed for versatile installation, delivering up to 6 years of battery life.

Technische Daten

Mounting

Adhesive and screw mount

Dimensions

Device with wall mount: 93.5 x 22.5 x 24.7 mm (3.7 x 0.89 x 0.97") Device with corner mount: 93.5 x 22.5 x 27.9 mm (3.7 x 0.89 x 1.1")

Hardware: LEDs

(1) Status: R/B/W (1) Signal: B/R

Hardware: Weight

45 g (1.6 oz)

Hardware: Buttons

(1) Factory reset (1) Function button (1) Tamper switch

Hardware: Display

1.14" status display

Performance: Thread

2400–2480 MHz

Software: Mobile App

UniFi Protect iOS™ and Android™

Hardware: Battery Life

Up to 6 years

Hardware: Power Method

Lithium battery CR123A

Performance: Bluetooth

2400–2480 MHz

Performance: SuperLink

US: 915.6–927.6 MHz EU: 865.1–869.5 MHz JP: 920.5–922.3 MHz

UniFi Application Suite

Protect

Hardware: Certifications

FCC, IC, CE

Hardware: Mount Material

Polycarbonate

Performance: Connectivity

SuperLink (Proprietary)

Software: Web Application

UniFi Protect

Hardware: Antenna Connector

(1) RP-SMA female

Hardware: Enclosure Material

Polycarbonate, high-density polyethylene (HDPE)

Hardware: Max. Power Consumption

22.6mW

Performance: Vertical PIR Sensor

Detection range up to 6 m (19.7 ft) with pet immunity

Hardware: Supported Voltage Range

3V

Performance: Networking Interface

(1) 10/100 MbE RJ45 port

Performance: Horizontal PIR Sensor

Detection range up to 1.5 m (4.9 ft)

Hardware: Ambient Operating Humidity

10 to 90% noncondensing

Hardware: Ambient Operating Temperature

0 to 40° C (32 to 104° F)
