Ubiquiti UICARE-ECS-24S-POE-EU
Ubiquiti · UICARE-ECS-24S-PoE-EU
Lieferzeit auf Anfrage
662,14 €inkl. MwSt., zzgl. Versand
Beschreibung
Enterprise-grade 48-port, Layer 3 Etherlighting™ PoE+++ switch with Stacking support and high-capacity 10 GbE RJ45 and 25G SFP28 connections for high availability system design.
Technische Daten
- Console
- 1
- 25G SFP28
- 4 (25G/10G/1G)
- 1 GbE RJ45
- 1 (1G/100M/10M)
- Dimensions
- 442.4 x 44 x 496 mm (17.4 x 1.7 x 19.5")
- Redundancy
- Switch Stacking (2) Hot-Swappable PSUs (4) Hot-Swappable Fans
- 10 GbE RJ45
- 16 (All PoE+++) (10G/5G/2.5G/1G/100M/10M)
- 100G QSFP28
- 2 (100G)
- Form Factor
- Rack Mount (1U, Full-Depth)
- 2.5 GbE RJ45
- 32 (All PoE+++) (2.5G/1G/100M/10M)
- Hardware: PoE
- 15.4W
- Hardware: PoE+
- 30W
- Hardware: PoE++
- 60W
- Max. PoE Output
- Up to PoE+++
- Hardware: PoE+++
- 48
- Hardware: Weight
- Without mounting brackets: 9.5 kg (20.9 lb) With mounting brackets: 9.6 kg (21.1 lb)
- Performance: MAC
- 256
- Performance: IPv4
- 256
- Hardware: Fan Method
- (4) Hot-swappable fan modules
- Hardware: Management
- Ethernet OOB Management port Serial Console AR
- Hardware: LCM Display
- 1.3" touchscreen
- Hardware: Power Method
- (2) Universal input, 100–240V AC, 50/60 Hz
- Hardware: Power Supply
- (2) Hot-swappable AC/DC 1,200W power modules
- Total PoE Availability
- 200-240V AC Shared Mode: 2,150W 100-120V AC Shared Mode: 1,750W 200-240V AC Redundant Mode: 950W 100-120V AC Redundant Mode: 750W
- Hardware: Certifications
- CE, FCC, IC
- Hardware: ESD Protection
- Air: ± 30kV, contact: ± 19kV
- Hardware: Mount Material
- SGCC steel
- Hardware: Heat Dissipation
- 853 BTU/hr (Excluding PoE Output)
- Hardware: Enclosure Material
- SGCC steel
- Hardware: Power Input Method
- (2) AC input, Hot-swappable power modules
- Performance: Forwarding Rate
- 506 Mpps
- Performance: Supported VLANs
- 1,000
- Hardware: Supported Rack Depth
- 482.6 mm (19") four-post racks Posts depths ranging from 650 to 1,000 mm (25.6–39.4”)
- Performance: IPv4 Static Routes
- 512
- Performance: Packet Buffer Size
- 8 MB
- Performance: Switching Capacity
- 680 Gbps
- Hardware: Max. Power Consumption
- 250W (Excluding PoE Output) 2,400W (Including PoE Output)
- Hardware: Supported Voltage Range
- 100–240V AC
- Performance: MAC Address Table Size
- 32,000
- Hardware: Ambient Operating Humidity
- 10 to 90% noncondensing
- Hardware: Ambient Operating Temperature
- -5 to 40° C (23 to 104° F)
- Performance: Total Non-Blocking Throughput
- 340 Gbps
