Ubiquiti Access G3 Starter Kit Professional
Ubiquiti · UA-G3-SK-Pro
sofort lieferbar
664,01 €inkl. MwSt., zzgl. Versand
Beschreibung
A switch with an integrated 368Wh lithium-ion battery capable of providing uninterruptible PoE to 8 devices.
Technische Daten
- Color
- Silver
- Weight
- 10.3 kg (22.7 lb)
- Mounting
- Floor stand
- U Height
- 6U
- Connector
- RJ45
- Materials
- Cold-rolled carbon steel (SPCC)
- Rack Type
- Open frame
- Treatment
- Liquid coating
- 1 GbE RJ45
- 9 (4 PoE+; 4 PoE++) (1G/100M/10M)
- Dimensions
- 442 x 480 x 44 mm (17.4 x 18.9 x 1.7")
- In the Box
- (1) Door Hub (1) G3 Reader Pro (1) G3 Reader (2) Pocket Keyfobs
- Redundancy
- Battery Power Backup
- Touch Pass
- 10 free 1-year Touch Passes included <a href="https://help.ui.com/hc/en-us/articles/27130425853079-UniFi-Access-Touch-Pass-Configuration" target="_blank" rel="noopener noreferrer">Learn More</a>
- Form Factor
- Rack mount (1U)
- Pack Options
- (1) Flat pack box
- Door Hub: LEDs
- B/W <a href="https://help.ui.com/hc/en-us/articles/25738084762775-UniFi-Access-Understand-Access-Device-LED-Status-Indicators" target="_blank" rel="noopener noreferrer">Learn More</a>
- Hardware: PoE+
- 4
- G3 Reader: LEDs
- R/G/B/W <a href="https://help.ui.com/hc/en-us/articles/25738084762775-UniFi-Access-Understand-Access-Device-LED-Status-Indicators" target="_blank" rel="noopener noreferrer">Learn More</a>
- Hardware: PoE++
- 4
- Max. PoE Output
- Up to PoE++
- Supported Media
- Copper
- Door Hub: Button
- (1) Factory reset
- Door Hub: Weight
- 363 g (12.8 oz)
- Hardware: Weight
- Without mount: 9 kg (19.9 lb) With mount: 9.2 kg (20.3 lb)
- G3 Reader: Button
- (1) Factory reset
- G3 Reader: Weight
- 82 g (2.9 oz)
- Door Hub: Mounting
- DIN-rail (Included)
- Enclosure Material
- Frame/Bracket: SPCC steel Handle: Stainless steel
- G3 Reader: Sensors
- Proximity sensor
- G3 Reader: Speaker
- (1) Yes, 0.7W
- G3 Reader Pro: LEDs
- R/G/B/W/Amber <a href="https://help.ui.com/hc/en-us/articles/25738084762775-UniFi-Access-Understand-Access-Device-LED-Status-Indicators" target="_blank" rel="noopener noreferrer">Learn More</a>
- G3 Reader Pro: Size
- 120 mm (4.7") diagonal
- G3 Reader: Mounting
- In-wall, gang box (Included) Junction box (Optional)
- Supported Data Rate
- 10 / 100 / 1000 Mbps
- Door Hub: Dimensions
- 174.9 x 126 x 32.9 mm (6.9 x 5 x 1.3")
- Hardware: Management
- Ethernet AR
- Incompatible Devices
- UniFi Switch (Gen1), US-24-250W US-24-500W US-48-500W US-48-750W USG USG-Pro-4 EdgeSwitch ES-24-250W ES-24-500W ES-48-500W ES-48-750W EdgeRouter ER-8 Others CKG2-RM ER-RMKIT UACC-Pro-Max-16-RM
- Max. Weight Capacity
- Single Toolless Mini Rack Static: 80 kg (176 lb) Rolling: 45 kg (99 lb) Double Toolless Mini Racks with Stacking Kit Static: 70 kg (154 lb) Rolling: 35 kg (77 lb)
- G3 Reader Pro: Button
- (1) Factory reset
- G3 Reader Pro: Weight
- 136 g (4.8 oz)
- G3 Reader: Dimensions
- 93 x 40 x 36.5 mm (3.7 x 1.6 x 1.4")
- Hardware: LCM Display
- 1.3" touchscreen
- Pocket Keyfob: Weight
- 16 g (0.56 oz)
- Door Hub: Power Method
- PoE++ UL 294 Power-limited Class 2 PSU UL 60950-1/62368-1 LPS/PS2 PSU
- Door Hub: UL 294 Level
- Destructive attack: Level I Line security: Level I Endurance: Level I Standby power: Level I
- G3 Reader Pro: Sensors
- Proximity sensor
- G3 Reader Pro: Speaker
- (1) Yes, 1.5W
- Hardware: Power Method
- Universal input, 100–240V AC, 50/60 Hz External battery input, 48V DC
- Hardware: Power Supply
- AC/DC, internal, 240W
- Max. Power Consumption
- 1.2W
- Total PoE Availability
- 120W
- Door Hub: Digital Input
- Request to exit, request to enter, remote release, door position sensor
- Door Hub: PoE Interface
- (1) PoE++ input, 50V DC, 1A (4) PoE outputs, 50V DC, 30W per port (Max 45W aggregated)
- G3 Reader Pro: Mounting
- Wall, gang-box mount (Included) Angle mount, junction box (Optional)
- G3 Reader: Connectivity
- BLE 4.1 NFC
- G3 Reader: Power Method
- PoE UL 294 Power-limited Class 2 PSU UL 60950-1/62368-1 LPS/PS2 PSU
- G3 Reader: UL 294 Level
- Destructive attack: Level I Line security: Level I Endurance: Level I Standby power: Level I
- Software: UniFi Network
- Version 6.2.26 and later
- Door Hub: Certifications
- CE, FCC, IC, UL 294, CAN/ULC-60839-11-1
- Door Hub: Mount Material
- Polycarbonate
- G3 Reader Pro: Luminance
- 480 nits (Typical)
- G3 Reader: NFC Frequency
- 13.56 MHz
- Hardware: Certifications
- CE, FCC, IC
- Hardware: ESD Protection
- Air/contact: ± 24kV
- Supported Cable Distance
- 100 m (328 ft)
- Door Hub: Input Terminals
- (2) Door exit request (1) Door position (1) Emergency
- Door Hub: Supported Doors
- 1
- G3 Reader Pro: Dimensions
- 160 x 40.4 x 40.55 mm (6.3 x 1.59 x 1.6")
- G3 Reader Pro: Resolution
- 2MP 1200 x 1600 (3:4)
- G3 Reader: Certifications
- CE, FCC, IC, UL 294, CAN/ULC-60839-11-1
- G3 Reader: Mount Material
- Aluminum alloy
- G3 Reader: NFC Read Range
- < 30 mm (1.18'')
- G3 Reader: NFC Technology
- ISO/IEC 14443A / 14443B / 15693 / 18092 (Ecma 340) MIFARE Classic / MIFARE DESFIRE Sony FeliCa™ (ID only) NFC Forum tags T1T, T2T, T3T, T4T and T5T ECP 2.0
- Pocket Keyfob: Dimensions
- 84 x 39 x 7.4 mm (3.3 x 1.5 x 0.29")
- Door Hub: Dry Output Relay
- Lock: 30V DC, 1A Aux: 30V DC, 1A
- Door Hub: Other locks (1A)
- 24 AWG length: 9 m (30 ft) 22 AWG length: 15 m (49 ft) 20 AWG length: 24 m (79 ft) 18 UACC-Cable-DoorLockRelay length: 36 m (118 ft)
- Door Hub: UL 294 Statement
- Compliance with IEEE 802.3 (at or af) specifications was not verified as part of UL 294. The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725
- G3 Reader: Weatherproofing
- IP55
- Hardware: Heat Dissipation
- 170.6 BTU/hr (Excluding PoE Output)
- G3 Reader Pro: Connectivity
- BLE 4.2 NFC
- G3 Reader Pro: Power Method
- PoE UL 294 Power-limited Class 2 PSU UL 60950-1/62368-1 LPS/PS2 PSU
- G3 Reader Pro: UL 294 Level
- Destructive attack: Level I Line security: Level I Endurance: Level I Standby power: Level I
- G3 Reader: UL 294 Statement
- Compliance with IEEE 802.3 specifications was not verified as part of UL 294. The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power
- Door Hub: Enclosure Material
- Polycarbonate
- Door Hub: Maximum User Count
- 6,000
- G3 Reader Pro: Field of View
- H: 98.6°, V: 125.7°, D: 157.8°
- G3 Reader Pro: NFC Frequency
- 13.56 MHz
- Hardware: Enclosure Material
- SGCC steel
- Hardware: Power Input Method
- AC input DC input (Backup)
- Performance: Forwarding Rate
- 13 Mpps
- Performance: Supported VLANs
- 1,000
- Pocket Keyfob: Certification
- CE
- Pocket Keyfob: NFC Frequency
- 13.56 MHz
- Ambient Operating Temperature
- 0 to 70° C (32 to 158° F)
- G3 Reader Pro: Certifications
- CE, FCC, IC,UL 294, CAN/ULC-60839-11-1
- G3 Reader Pro: Mount Material
- Aluminum alloy
- G3 Reader Pro: NFC Read Range
- < 30 mm (1.18'')
- G3 Reader Pro: NFC Technology
- ISO/IEC 14443A / 14443B / 15693 / 18092 (Ecma 340) MIFARE Classic / MIFARE DESFIRE Sony FeliCa™ (ID only) NFC Forum tags T1T, T2T, T3T, T4T and T5T ECP 2.0
- G3 Reader: ESD/EMP Protection
- Air: ± 15kV, contact: ± 8kV
- G3 Reader: Enclosure Material
- Polycarbonate, glass
- Pocket Keyfob: NFC Technology
- ISO/IEC 14443 Type A MIFARE DESFire EV3 4K UniFi Access Proprietary Security Protocol
- Door Hub: Networking Interface
- (5) 10/100/1000 Base-T
- Door Hub: Powered Output Relay
- Lock: 12V DC, 1A Aux: 12V DC, 0.33A 12V DC, 0.33A
- Door Hub: Software Information
- The software version can be checked at <a href="https://unifi.ui.com/" target="_blank" rel="noopener noreferrer">https://unifi.ui.com</a>
- G3 Reader Pro: Max. Frame Rate
- 30 FPS
- G3 Reader Pro: Weatherproofing
- IP55
- Hardware: Supported Rack Depth
- 482.6 mm (19") four-post racks Posts depths ranging from 700 to 1,000 mm (27.6–39.4”)
- Pocket Keyfob: Weatherproofing
- IP54
- G3 Reader Pro: UL 294 Statement
- Compliance with IEEE 802.3 specifications was not verified as part of UL 294. The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power
- G3 Reader: Networking Interface
- (1) 10/100 MbE RJ45 port
- G3 Reader: Software Information
- The software version can be checked at <a href="https://unifi.ui.com/" target="_blank" rel="noopener noreferrer">https://unifi.ui.com</a>
- Performance: Packet Buffer Size
- 0.5 MB
- Performance: Switching Capacity
- 18 Gbps
- Door Hub: Management Application
- UniFi Access
- Door Hub: Max. Power Consumption
- 30W (Without PoE output) 50W (With PoE output)
- G3 Reader Pro: Screen Technology
- Capacitive touch
- Hardware: Max. Power Consumption
- 50W (Excluding PoE Output) 240W (Including PoE Output and AC Output)
- G3 Reader Pro: ESD/EMP Protection
- Air: ±15kV, contact: ±8kV
- G3 Reader Pro: Enclosure Material
- Polycarbonate, glass
- G3 Reader Pro: Screen Orientation
- Portrait
- G3 Reader: Management Application
- UniFi Access
- G3 Reader: Max. Power Consumption
- 5W
- Hardware: Supported Voltage Range
- 100–240V AC
- Pocket Keyfob: Enclosure Material
- Polycarbonate, stainless steel, silicone rubber
- Door Hub: CAN/ULC-60839-11-1 Grade
- Grade assignment: 1
- Door Hub: PoE Cabling Requirements
- Cat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site. The minimal conductor gauge per
- Door Hub: UA-Lock-Electric (400mA)
- 24 AWG length: 25 m (82 ft) 22 AWG length: 42 m (138 ft) 20 AWG length: 66 m (217 ft) 18 UACC-Cable-DoorLockRelay length: 100 m (328 ft)
- G3 Reader: Supported Voltage Range
- 48V DC
- G3 Reader Pro: Networking Interface
- (1) GbE RJ45 port
- G3 Reader Pro: Software Information
- The software version can be checked at <a href="https://unifi.ui.com/" target="_blank" rel="noopener noreferrer">https://unifi.ui.com</a>
- G3 Reader: CAN/ULC-60839-11-1 Grade
- Grade assignment: I
- G3 Reader: PoE Cabling Requirements
- Cat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site. The minimal conductor gauge per
- Performance: MAC Address Table Size
- 8,000
- Door Hub: Ambient Operating Humidity
- 5 to 95% noncondensing
- Hardware: Ambient Operating Humidity
- 5 to 95% noncondensing
- G3 Reader Pro: Management Application
- UniFi Access
- G3 Reader Pro: Max. Power Consumption
- 6W
- G3 Reader: Ambient Operating Humidity
- 5 to 90% noncondensing
- G3 Reader Pro: Supported Voltage Range
- 48V DC
- Door Hub: Ambient Operating Temperature
- 0 to 40° C (32 to 104° F)
- G3 Reader Pro: CAN/ULC-60839-11-1 Grade
- Grade assignment: I
- G3 Reader Pro: PoE Cabling Requirements
- Cat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site. The minimal conductor gauge per
- Hardware: Ambient Operating Temperature
- -5 to 40° C (23 to 104° F)
- Door Hub: UA-Lock-Magnetic-270kg (800mA)
- 24 AWG length: 12 m (39 ft) 22 AWG length: 20 m (66 ft) 20 AWG length: 30 m (98 ft) 18 UACC-Cable-DoorLockRelay length: 46 m (151 ft)
- Door Hub: UA-Lock-Magnetic-540kg (500mA)
- 24 AWG length: 20 m (66 ft) 22 AWG length: 32 m (105 ft) 20 AWG length: 51 m (167 ft) 18 UACC-Cable-DoorLockRelay length: 80 m (262 ft)
- G3 Reader: Ambient Operating Temperature
- -30 to 45° C (-22 to 113° F)
- G3 Reader Pro: Ambient Operating Humidity
- 5 to 90% noncondensing
- Pocket Keyfob: Ambient Operating Humidity
- 10 to 90% noncondensing
- Performance: Total Non-Blocking Throughput
- 9 Gbps
- G3 Reader Pro: Ambient Operating Temperature
- Device: -30 to 45° C (-22 to 113° F) Display: -10 to 45° C (14 to 113° F)
- Pocket Keyfob: Ambient Operating Temperature
- -10 to 45° C (14 to 113° F)
- Door Hub: Document number, and issue date and/or revision le
- UA-Hub-Door002, V01
- G3 Reader Pro: Document number, and issue date and/or revisi
- UA-G3-Pro-W/UA-G3-Pro-B, V01
- G3 Reader: Document number, and issue date and/or revision l
- UA-G3, V01
